Phase-separated PS/PVAC blend exhibiting nanoscale compositional heterogeneity and distinct IR absorption characteristics from each polymer component.

PiFM imaging at 1250 cm⁻¹ selectively enhances the PVAC-related vibrational response, clearly visualizing the chemical distribution and domain contrast across the heterogeneous blend.


Scanning Conditions
- System: Nano-IR
- Scan Mode: PiFM
- Scan Size: 5 µm×5 µm
- Scan Rate: 0.5 Hz
- Pixel Size: 1024x1024 pixels
- Cantilever: PPP-NCHPt
(k=42 N/m, f=330 kHz)
